Spacetronik 4K HDMI to LAN Converter Spacetronik IR SPH-HLC55 KVM Kit
HDMI extender enables transmission and extension of uncompressed HDMI 1080p signal via CAT 5e/6 network cable, transmission distance is up to 60 meters in FullHD resolution with zero latency. The kit includes a transmitter unit (TX) and a receiver unit (RX) working as a pair, IR transmitter and receiver. The unit has LKV functions for remote control of the unit using a mouse or keyboard.
Full HD transmission over long distances
The SPH-HLC55 KVM device can transmit media without delay in 1080p quality over a distance of as much as 60m using CAT5e/6 cables.
A huge amount of technology in a small device
The SPH-HLC55 KVM features a host of cutting-edge technology. Among the most important are:
- 1080p resolution of transmitted data
- Zero latency
- Anti-voltage, anti-static and short-circuit protection
- HDMI port on the transmitter for additional screen (loop)
- Possibility of continuous operation 24/7
- IR signal transmission
- Audio transmission
Example wiring diagram of Spacetronik IP SPH-HLC55 KVM transmitter
You can connect devices to the transmitter via HDMI - e.g. cameras, PCs, DVDs, TV boxes, etc. An additional HDMI output allows you to connect a monitor straight to the transmitter. The main signal via CAT5e/6 cable is sent to the receiver at a distance of up to 60m.
SPH-HLC55 KVM HDMI Extender Specifications:
- CAT5e/6 cable length between Rx and TX: up to 60m
- HDMI input: 1080p / 720p / 576p / 576i / 480p / 480i
- HDMI output: 1080p / 720p / 576p / 576i / 480p / 480i
- HDMI version 1.4
- Power supply: DC 5V/2A
